Almere Station solar panel architecture

PixaLucid

Endless Transparent Product Designs

skylights roof atrium facade solar panel

THE POWER YOU CAN SEE

Activate your building glass

PixaLucid is a translucent building material integrated with high-efficient solar cells. Ideal for replacing the transparent areas on the building envelopes and turning the dummy glass into an active glass to harvest green energy. Fully adjustable cell coverage and layout allow a specific amount of sunlight to pass through.

APPLICATION SCENARIOS

Warm facade, Skylight & Balcony

Fully adjustable glass thickness and size make the panel ideal for replacing the transparent areas on the building envelopes such as warm facades, skylights, and balconies. It turns the dummy glass into an active glass to harvest green energy.

DESIGN FLEXIBITY

Your clarity at your command

The coverage of solar cells can be customized based on the required light transmittance for the interior area and nominal power required for the building permit; On top of that, the layout design of the solar cells can be arranged in different sequences creating a unique identity for the facade.

solar panel cell layout

INNOVATIVE DESIGN

Lucid stripe panel

The stripe-shaped solar cell arrangement gives the softness between light and shadow and creates a different aesthetic for the application of balcony and glass facade. In other words, our new solutions have redefined the effect of light through glass solar panels.

Contact Us

Thanks for submitting!

  • LinkedIn
  • Facebook
  • Black Instagram Icon
  • Black Twitter Icon
  • Flickr
Characteristics

Length

Width

Weight​





Front glass​





Rear glass





Coloring / texture





Encapsulation





Structure

600 mm - 3000 mm

( in multiples of 300mm )

600 mm - 3000 mm

( in multiples of 300mm )



28 kg / m² ( 5 + 5mm )





3mm - 10mm tempered glass





3 mm - 10 mm tempered glass





Full black in glossy / semi-matte / matte finish





PVB film

Frameless

Type

Power





Working

temperature





Connector





Cables / plugs





Warranty

Mono c-Si solar cell

70-200 Wp / m²

-40 ° C to + 85 ° C

IP68 at rear





4mm² / Original MC4





10-year workmanship warranty



30-year linear performance warranty up to 80%

Temp Coëfficiënt

Power

- 0.41 %/K

Isc

+ 0.039 %/K

VOC

- 0.30 %/K

PANEL INFORMATION

TECHNICAL INFORMATION
